Home > Products > LCD advertising machine > wall


分享到:

Model: LY-AH1500/AH1500N
Name: 15 inch Wall mount LCD Digital Signage

Description: 1. The scheme of professional LCD screen and sleek slim;
2. Support 1080 p hd broadcast, flow subtitles, split screen function;
3. Online support remote release management, the use of flexible cable, WIFI, 3 g network running.

  • Attribute
  • Picture
  • Customer



Standalone version  features Network version features
Model No LY-AH1500 Model No LY-AH1500N
Ports 1xUSB2.0,1xCF,1xSD Ports 1xUSB2.0,1xSATA,1xSD
storage medium U disk ,CF card,SD card storage medium U disk ,CF card,SD card,
SD Card, HDD
Video format MPG,MPG-1,MPG-2,MPG-4,AVI,MP4
DIV,TS,TRP,MKV,WMV,RM,RMVB
Video format MPG,MPG-1,MPG-2,MPG-4,AVI,MP4,
TS,MKV,WMV
Maximum resolution 1920*1080 Maximum resolution 1920*1080
Image format JPEG,PNG,BMP Image format GIF,JPEG,PNG,BMP
Audio output 2x5W Audio output 2x5W
Max frame rate 30frm/s Audio format MP3,24bit linear PCM7.1
The audio sampling rate 32KHZ,44.1KHZ,48KHZ,96KHZ operating environment WIN7/10,android
The largest color depth 24bit Networking way RJ45 Port, wifi(optional), 3G(Optional)
The largest stream USB2.0 device:30MB/S Program update way Network remote update, U disk update


Panel Specification
Panel size 15”LCD Panel
Display area 306(W)*230(H)
Display mode 4:3
Back light LED
Resolution 1280*1024
Display color 16.7M
Brightness (nits) 300cd/m2
Brightness (nits) 2000:1
Visual angle  175°(H) / 175°(V)
Response time 6ms
 Color system PAL/NTSC/SECAM
Life(hrs) 60000
Power supply

Power supply AC100V~240V
Maximum power consumption ≤30W
Standby power consumption ≤3W
Temperature Working temperature 0℃~40℃
Storage temperature -20℃~60℃
Working humidity 10%~90%
Storage humidity 10%~90%
Appearance Installation Wall-mounted
Body dimension(Lx W x H)mm 329×258×55(mm)
Net weight 6.5KG
